Specifications:
|
Access Control
|
Source/Destination IP Based Access Control / FQDN |
|
WEB Group Filtering§
URL Categories and URLs Filtering Web Security§) |
|
Sending GARP Packets§ |
|
TCP/UDP/ICMP Flood Defense |
|
Standards and Protocols
|
IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q |
|
Interface
|
Gigabit SFP WAN/LAN Port |
|
10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
|
Fan Quantity
|
Fanless
|
|
Button
|
Reset Button
|
|
Power Supply
|
12V DC/ 1A Power Adapter
|
|
Flash
|
128 MB NAND |
|
DRAM
|
512 MB DDR4 |
|
LED
|
PWR, SYS, SFP, USB, WAN(1000M Link/Act, 100/10M Link/Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act) |
| Dimensions ( W x D x H ) | 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) |
|
Protection
|
I4 kV surge protection |
|
Enclosure
|
Steel |
|
Mounting
|
Desktop/ Wall-Mounting/Rack-Mounting |
|
Max. Power Consumption
|
7.5 W (with USB 3.0 connected) |
|
IPS Throughput
|
TCP: 229 Mbps; |
|
DPI Throughput
|
TCP: 933 Mbps; |
|
WireGuard VPN
|
341.3 Mbps |
|
Concurrent Session
|
150,000 |
|
New Sessions /Second
|
5,300 |
|
NAT (Static IP)
|
945.3 Mbps / 940.5 Mbps |
|
NAT(DHCP)
|
939.6 Mbps / 940.9 Mbps |
|
NAT(PPPoE)
|
943.6 Mbps / 940.9 Mbps |
|
NAT (L2TP)
|
880.1 Mbps / 859.0 Mbps |
|
NAT (PPTP)
|
855.0 Mbps / 907.2 Mbps |
|
IPsec VPN Throughput
|
ESP-SHA1-AES256: 617.1 Mbps |
|
OpenVPN
|
139.1 Mbps |
|
L2TP VPN Throughput
|
Unencrypted: 977.4 Mbps |
|
PPTP VPN Throughput
|
Unencrypted: 1064.1 Mbps |
|
SSL VPN Throughput
|
131.6 Mbps |
|
66 Byte Packet Forwarding Rate
|
1,453,489 pps / 1,453,488 pps |
|
1,518 Byte Packet forwarding rate
|
81,279 pps / 81,275 pps |
|
WAN Connection Type
|
Static IP |
|
MAC Clone
|
Modify WAN/LAN MAC Address† |
|
DHCP
|
DHCP Server |
|
IPv6
|
StaticIP/SLAAC/DHCPv6/PPPoE/6to4Tunnel/PassThrough/Non-Address mode |
|
VLAN
|
802.1Q VLAN |
|
IPTV
|
IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
|
Access Control
|
IP/Port/Protocol/Domain Name Filtering |
|
Advanced Routing
|
Static Routing |
|
Bandwidth Control
|
IP-based Bandwidth Control |
|
Load Balance
|
Intelligent Load Balance |
|
NAT
|
One-to-One NAT |
|
Session Limit
|
IP-based Session Limit |
|
GRE
|
√ (Only in Standalone Mode) |
|
SD-WAN
|
√ (Only in Controller Mode) |
|
SSL VPN
|
50 Tunnels |
|
IPsec VPN
|
100 IPSec VPN Tunnels |
|
PPTP VPN
|
PPTP VPN Server |
|
PPTP VPN
|
L2TP VPN Server |
|
OpenVPN
|
OpenVPN Server |
|
WireGuard VPN
|
20 Tunnels |
|
Web Authentication
|
No Authentication |
|
Omada App
|
Yes. Requires the use of Omada Hardware Controller, Omada Central (Cloud-Based), or Omada Software Controller. |
|
Centralized Management
|
Omada Central (Cloud-Based) |
|
Cloud Access
|
Yes. Requires the use of Omada Hardware Controller, Omada Central (Cloud-Based), or Omada Software Controller. |
|
Service
|
Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) |
|
Maintenance
|
Web Management Interface |
|
Zero-Touch Provisioning
|
Yes. |
|
Management Features
|
Automatic Device Discovery |
|
Certification
|
CE, FCC, RoHS |
|
Package Content
|
ER7206 |
|
System Requirements
|
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10 MAC OS, NetWare, UNIX or Linux |
|
Environment
|
Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) |
