xSpecifications:
|
HARDWARE FEATURES
|
|
|
Standards and Protocols
|
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p |
|
Interface
|
16 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) 2 100/1000Mbps SFP Slots 1 RJ45 Console Port 1 Micro-USB Console Port |
|
Network Media
|
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) 100BASE-FX: MMF, SMF 1000BASE-X: MMF, SMF |
|
Fan Quantity
|
0 |
|
Physical Security Lock
|
Yes |
|
Power Supply
|
100~240VAC, 50/60Hz |
|
Dimensions ( W x D x H )
|
17.3*8.7*1.7 in.(440*220*44 mm) |
|
Mounting
|
Rack Mountable |
|
Max. Power Consumption
|
11.47W (220V/50Hz) |
|
Max. Heat Dissipation
|
39.14 BTU/h |
|
PERFORMANCE
|
|
|
Switching Capacity
|
36Gbps |
|
Packet Forwarding Rate
|
26.78Mpps |
|
MAC Address Table
|
8k |
|
Jumbo Frame
|
9216 Bytes |
|
SOFTWARE FEATURES
|
|
|
Quality of Service
|
Support 802.1p CoS/DSCP priority Support 8 priority queues Queue scheduling: SP, WRR, SP+WRR Port/Flow- based Rate Limiting Voice VLAN |
|
L2 and L2+ Features
|
Static Routing DHCP Relay IGMP Snooping V1/V2/V3 802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group) STP/RSTP/MSTP BPDU Filtering/Guard TC/Root Protect Loopback detection 802.3x Flow Control L2PT |
|
VLAN
|
Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs) 802.1Q/MAC/Protocol-based VLAN GARP/GVRP |
|
Access Control List
|
L2~L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p,DSCP, protocol and VLAN ID Time Range Based ACL |
|
Security
|
IP-MAC-Port Binding AAA 802.1x and Radius Authentication DoS Defend Dynamic ARP Inspection (DAI) SSH v1/v2 SSL v3/TLSv1 Port Security Broadcast/Multicast/Unknown-unicast Storm Control |
|
IPv6
|
DHCPv6 Client Ping6 Tracert6 Telnet(v6) IPv6 SNMP IPv6 SSH IPv6 SSL Http/Https IPv6 TFTP IPv6 ACL IPv6 Interface IPv6 Routing DHCPv6 Snooping |
|
Management Features
|
Web-based GUI and CLI management SNMP v1/v2c/v3,compatible with public MIBs and TP-Link private MIBs RMON (1, 2, 3, 9 groups) PPPoE Circuit ID DHCP Relay DHCP Server DHCP/BOOTP Client, DHCP Snooping, DHCP Option82 Dual Image CPU Monitoring Port Mirroring DDM Time Setting: SNTP Firmware Upgrade: TFTP & Web System Diagnose: VCT SYSLOG & Public MIBS Password Recovery |
|
OTHERS
|
|
|
Certification
|
CE, FCC, RoHS |
|
Package Content
|
Switch Power Cord Quick Installation Guide Resource CD Rackmount Kit Rubber Feet |
|
System Requirements
|
Microsoft® Windows® XP, Vista™, 7, 8, 10, MAC® OS, NetWare®, UNIX® or Linux. |
|
Environment
|
Operating Temperature: 0℃~45℃ (32℉~113℉); Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
