Description
xSpecifications:
|
Processor
|
Qualcomm 750MHz CPU, MIPS 74Kc |
|
Memory
|
128 MB DDR2 RAM, 16 MB Flash |
|
Interface
|
1 10/100/1000 Mbps Shielded Ethernet Port (LAN/POE) |
|
Power Supply
|
Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) |
|
Dimensions ( W x D x H )
|
366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) |
|
23 dBi
|
|
Antenna Beamwidth
|
9° (Azimuth)/7° (Elevation) |
|
Protection
|
15 KV ESD Protection |
|
Enclosure
|
Material: Outdoor PC stabilized plastic |
|
Wireless Standards
|
IEEE 802.11a/n/ac |
|
Wireless Speeds
|
Up to 867 Mbps (80 MHz, Dynamic) |
|
Frequency
|
5.15–5.85 GHz
|
|
Transmission Power
|
Max. 27 dBm (Adjustable power by 1dBm) |
|
Network Configuration
|
WAN: Static/ Dynamic/ PPPoE |
|
Wireless Configurations
|
Selectable Channel Width: 20/40/80MHz |
|
Management Features
|
Discovery and Remote Management via Pharos Control application |
|
System Tools
|
Indicators: Signal Strength/ Noise/ Transmit CCQ/ CPU/ Memory |
|
System-level Optimizations
|
Optimized IGMP Snooping / Proxy for multicast applications |
|
POE ADAPTER FEATURES
|
Dimensions(W x D x H): 85.8×43.9×29.7 mm Interfaces: 1 AC Jack with Earth Ground, 1× 10/100/1000 Mbps Shielded Ethernet Port (Power + Data), 1× 10/100/1000 Mbps Shielded Ethernet Port (Data) Button: Remote Reset Button Power Status LEDs: Green Input: 100-240VAC, 50/60Hz Output: 24VDC, 0.5A Max, +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet) Efficiency: >84.29% Certifications: CE/FCC/UL/IC/GS/PSB/SAA/S-Mark/KC-mark |
|
Certification
|
CE, FCC, RoHS, IP65, IC |
|
Package Content
|
Outdoor Wireless CPE |
|
System Requirements
|
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. |
|
Environment
|
Operating Temperature: -40℃~70℃ (-40℉~158℉) |
