Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°
Currency
Description
xFeatures
- High quality imaging with 4 MP resolution
- Efficient H.265+ compression technology to save bandwidth and storage
- Clear imaging against strong back light due to 120 dB true WDR technology
- Water and dust resistant (IP67)
- 3D DNR technology delivers clean and sharp images
- Easy installation with Power over Ethernet (PoE) technology
SPECIFICATION:
|
Image Sensor
|
1/3" progressive scan CMOS
|
|
Min. Illumination
|
Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
|
|
Shutter Speed
|
1/3 s to 1/100, 000 s
|
|
Slow Shutter
|
Yes |
|
Wide Dynamic Range
|
120 dB
|
|
Day & Night
|
IR cut filter
|
|
Angle Adjustment
|
|
|
Focal Length & FOV
|
2.8 mm, horizontal FOV 98.0°, vertical FOV 53.1°, diagonal FOV 114.7° 4 mm, horizontal FOV 78.7°, vertical FOV 43.1°, diagonal FOV 92.3°
|
|
Lens Mount
|
M12 |
| Focus | Fixed |
| Aperture | F2.0 |
|
IR Wavelength
|
850 nm
|
|
IR Range
|
|
|
Max. Resolution
|
2560 × 1440
|
|
Main Stream
|
50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 30 fps (1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
|
|
Video Compression
|
Main stream: H.265/H.264/H.265+/H.264+ Sub-stream: H.265/H.264/MJPEG
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
Baseline Profile/Main Profile/High Profile
|
|
H.265 Type
|
Main Profile
|
|
H.264+
|
Main stream supports
|
|
H.265+
|
Main stream supports
|
|
Region of Interest (ROI)
|
|
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
API
|
Open Network Video Interface, ISAPI
|
|
User/Host
|
Up to 32 users. 3 levels: administrator, operator and user
|
| Client |
iVMS-4200, Hik-Connect
|
|
Web Browser
|
|
|
Image Settings
|
|
|
Day/Night Switch
|
|
|
Image Enhancement
|
|
|
Ethernet Interface
|
|
|
Basic Event
|
|
|
Linkage Method
|
|
|
Camera Material
|
|
|
Camera Dimension
|
|
|
Package Dimension
|
|
|
Camera Weight
|
|
|
With Package Weight
|
|
|
Storage Conditions
|
|
|
Startup and Operating Conditions
|
|
|
General Function
|
|
|
Firmware Version
|
|
|
Power Consumption and Current
|
|
|
Power Supply
|
|
|
Power Interface
|
|
|
Protection
|
Warranty
