AI by Device
|
Facial recognition, perimeter protection, motion detection 2.0
|
|
AI by Camera
|
Facial recognition, perimeter protection, throwing objects from building, motion detection2.0, ANPR, VCA
|
|
Facial Detection and Analytics
|
Face picture comparison, human face capture, face picture search
|
|
Face Picture Library
|
Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 1 GB)
|
|
Facial Detection and Analytics Performance
|
1-ch, 8 MP
|
|
Face Picture Comparison
|
4-ch
|
|
By Camera
|
All channels
|
|
By Device
|
2-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
|
|
By Camera
|
All channels
|
|
IP Video Input
|
16-ch
|
|
Incoming Bandwidth
|
160 Mbps
|
|
Outgoing Bandwidth
|
160 Mbps
|
|
HDMI Output
|
1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
|
|
VGA Output
|
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
|
|
Video Output Mode
|
HDMI/VGA independent output
|
|
CVBS Output
|
N/A
|
|
Audio Output
|
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
|
|
Two-Way Audio
|
1-ch, RCA (Linear, 1 KΩ)
|
|
Decoding Format
|
H.265/H.265+/H.264+/H.264
|
|
Recording Resolution
|
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
|
|
Synchronous playback
|
16-ch
|
|
Decoding Capability
|
AI on: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p (30 fps) AI off: 2-ch@12 MP (30 fps)/4-ch@8 MP (30 fps)/8-ch@4 MP (30 fps)/16-ch@1080p (30 fps) Smooth Playback (HC) ON & AI ON: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/5-ch@4 MP (30 fps)/11-ch@1080p (30 fps) Smooth Playback (HC) ON & AI OFF: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/7-ch@4 MP (30 fps)/15-ch@1080p (30 fps)
|
|
Stream Type
|
Video, Video & Audio
|
|
Audio Compression
|
G.711ulaw/G.711alaw/G.722/G.726/AAC
|
|
Remote Connection
|
128
|
| API |
ONVIF (profile S/G); SDK; ISAPI
|
|
Compatible Browser
|
IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
|
|
Network Protocol
|
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
|
|
Network Interface
|
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
|
SATA
|
2 SATA interfaces
|
|
Capacity
|
Up to 16 TB capacity for each HDD
|
|
USB Interface
|
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
|
|
Alarm In/Out
|
4/1
|
|
Power Supply
|
12 VDC, 3.3 A
|
|
Consumption
|
≤ 15 W (without HDD)
|
|
Working Temperature
|
-10 °C to 55 °C (14 °F to 131 °F)
|
|
Working Humidity
|
10% to 90%
|
|
Dimension (W × D × H)
|
385 mm × 315 mm × 52 mm (15.2"× 12.4" × 2.0")
≤ 1 kg (without HDD, 2.2 lb.)
|
|
Obtained Certification
|
CE, FCC, IC, CB, KC, UL, Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS
|
