AI by NVR
|
Facial recognition, perimeter protection, motion detection 2.0
|
|
AI by Camera
|
Facial recognition, perimeter protection, video structuralization, throwing objects from building, motion detection 2.0, ANPR, people counting, VCA
|
| Engine |
1, engine mode is adjustable
|
|
Face Picture Library
|
Up to 16 face picture libraries, with up to 50,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 1 GB)
|
|
Face Picture Comparison
|
8-ch
|
|
Facial Detection and Analytics
|
Face picture comparison, human face capture, face picture search
|
|
Facial Detection and Analytics Performance
|
4-ch human face capture (HD network camera, up to 8 MP, H.264/H.265)
|
|
By Camera
|
All channels
|
|
Human/Vehicle Analysis
|
N/A
|
|
By NVR
|
All channels for Hikvision cameras
|
|
By Camera
|
All channels
|
|
Human/Vehicle Analysis
|
N/A
|
|
By NVR
|
4-ch, 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm; Up to 12 rules in total
|
|
By Camera
|
All channels
|
|
Vehicle Attributes
|
Plate number, license plate color, license plate type
|
|
Plate Attributes
|
Vehicle brand, vehicle color, vehicle type
|
|
IP Video Input
|
16-ch
|
|
Incoming Bandwidth
|
160 Mbps
|
|
Outgoing Bandwidth
|
256 Mbps
|
|
HDMI Output
|
4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz
|
|
VGA Output
|
1920 × 1080/60 Hz
|
|
Video Output Mode
|
HDMI/VGA independent output
|
|
CVBS Output
|
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
|
|
Audio Output
|
1-ch, RCA (Linear, 1 KΩ)
|
|
Two-Way Audio
|
1-ch, RCA (2.0 Vp-p, 1 KΩ)
|
|
Decoding Format
|
H.265+/H.265/H.264+/H.264
|
|
Recording Resolution
|
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF 32MP/24MP/12MP/8MP/7MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF *: The NVR supports up to 4-ch 32 MP/24 MP IP video inputs.
|
|
Synchronous playback
|
16-ch
|
|
Live View Window Division
|
1/2/4/6/8/9/16
|
|
Aux Port Window Division
|
1/2/4/6/8/9/16
|
|
Decoding Capability
|
Enable AI by NVR: 20-ch@1080p (30 fps) Disable AI by NVR: 32-ch@1080p (30 fps)
|
|
Audio Compression
|
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM
|
|
Dual-Stream Recording
|
Support
|
|
Stream Type
|
Video, Video & Audio
|
|
Network Interface
|
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
|
Remote Connection
|
128
|
|
Network Protocol
|
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
|
| API |
ONVIF (profile S/G); SDK; ISAPI
|
|
Compatible Browser
|
IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
|
|
Camera Access Protocol
|
ONVIF(Version 2.5), RTSP
|
|
SATA
|
2 SATA interfaces
|
|
Capacity
|
Up to 14 TB capacity for each disk
|
|
Serial Interface
|
N/A
|
|
Alarm In/Out
|
4/1
|
|
USB Interface
|
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
|
|
Power Supply
|
100 to 240 VAC, 50 to 60 Hz
|
|
Consumption
|
≤ 30 W (without HDD)
|
|
Working Temperature
|
-10° C to 55° C (14° F to 131° F)
|
|
Working Humidity
|
10% to 90%
|
|
Chassis
|
1U chassis
|
|
Dimension (W × D × H)
|
385 × 317 × 52 mm ( 15.2"× 12.5" × 2.0")
|
|
Weight
|
≤ 2.5 kg (without HDD, 5.5 lb.)
|
|
CE
|
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
|
