Image Sensor
|
1/2.8" Progressive Scan CMOS
|
|
Min. Illumination
|
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
Slow Shutter
|
Yes |
|
Wide Dynamic Range
|
120dB
|
|
Day & Night
|
IR Cut Filter
|
|
Angle Adjustment
|
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
|
|
Focus
|
Auto |
|
Lens Type
|
2.8 to 12 mm, Motorized
|
| FOV |
horizontal FOV: 110° to 31°,vertical FOV: 58° to 18°,diagonal FOV: 136° to 36°
|
|
Aperture
|
F1.6
|
|
Lens Mount
|
Φ14
|
|
Aperture Type
|
Fixed
|
|
IR Range
|
Up to 30 m
|
|
Wavelength
|
850nm
|
|
Max. Resolution
|
1920 × 1080
|
|
Main Stream
|
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub Stream
|
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
|
Third Stream
|
50Hz: 25fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288),60Hz: 30fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 240)
|
|
Video Compression
|
Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
H.264 Type
|
Main Profile/High Profile
|
|
H.265 Type
|
Main Profile
|
|
H.264+
|
Main stream supports
|
|
H.265+
|
Main stream supports
|
|
Scalable Video Coding (SVC)
|
H.264 and H.265 encoding
|
|
Environment Noise Filtering
|
Yes
|
|
Audio Sampling Rate
|
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
|
|
Audio Compression
|
G722.1/G.711/G726/MP2L2/PCM/MP3
|
|
Audio Bit Rate
|
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3)
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
API
|
ONVIF (PROFILE S, PROFILE G), ISAPI
|
|
Protocols
|
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
|
|
User/Host
|
Up to 32 users,3 levels: Administrator, Operator and User
|
|
Network Storage
|
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
|
| Client |
iVMS-4200, Hik-Connect, Hik-Central
|
|
Web Browser
|
Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local Service: Chrome 41.0+, Firefox 30.0+
|
|
Alarm Trigger
|
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error
|
|
Day/Night Switch
|
Day/Night/Auto/Schedule/Triggered by alarm in (-S)
|
| DNR |
3D DNR
|
|
Image Enhancement
|
BLC/3D DNR/HLC
|
|
Image Settings
|
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
|
|
Audio
|
-S: 1 input (line in/mic.in), 1 output (line out), mono sound, terminal block
|
| Alarm |
-S: 1 input; 1 output (max. 12 VDC, 30 mA), terminal block
|
|
On-board Storage
|
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
|
|
Hardware Reset
|
Yes
|
|
Communication Interface
|
1 RJ45 10M/100M self-adaptive Ethernet port
|
|
Video Output
|
1 Vp-p Composite Output(75Ω) (For adjustment only)
|
|
Basic Event
|
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
|
|
Smart Event
|
Line crossing detection, intrusion detection, face detection
|
|
Face Detection
|
Yes |
|
Linkage Method
|
Trigger recording: memory card, network storage, pre-record and post-record
Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output , Email |
|
Firmware Version
|
5.6.3
|
|
General Function
|
One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
|
|
Startup and Operating Conditions
|
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, terminal block,PoE (802.3af, class 3)
|
|
Power Consumption and Current
|
12 VDC, 0.8A, max. 10W,PoE (802.3af, 36V to 57V), 0.35A to 0.2A, max. 12W
|
|
Camera Dimension
|
Camera: Φ 153.3 × 111.6mm (Φ 6" × 4.4")
|
|
Camera Weight
|
Camera: Approx. 835g (1.8 lb.),With Package: Approx. 1305g (2.9 lb.)
|
|
Protection
|
IP67, IK10
|
