Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Currency
Description
xFeatures
- High quality imaging with 4 MP resolution
- Excellent low-light performance via powered-by-DarkFighter technology
- Efficient H.265+ compression technology
- Clear imaging against strong back light due to 120 dB true WDR technology
- Water and dust resistant (IP66) and vandal proof (IK10)
- Motorized varifocal lens for easy installation and monitoring
- Robust structure design with full metal materials.
SPECIFICATION:
|
Image Sensor
|
1/2.5" Progressive Scan CMOS
|
|
Min. Illumination
|
Color: 0.008 lux @(F1.2, AGC ON), 0.011 lux @(F1.4, AGC ON), 0 lux with IR
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
Slow Shutter
|
Yes |
|
Wide Dynamic Range
|
120dB |
|
Day & Night
|
IR Cut Filter
|
|
Angle Adjustment
|
|
|
Focus
|
Auto |
|
Lens Type
|
2.8 to 12 mm，Motorized
|
| FOV |
2.8 mm to 12 mm, horizontal FOV: 114° to 32°, vertical FOV: 59° to 18°, diagonal FOV: 141° to 36.5°
|
|
Aperture
|
F1.4
|
|
Lens Mount
|
|
|
IR Range
|
Up to 50 m
|
|
Wavelength
|
850nm |
|
Max. Resolution
|
2688 × 1520
|
|
Main Stream
|
50Hz: 25fps (2688 × 1520, 2304 × 1296, 1920 × 1080) 60Hz: 30fps (2688 × 1520, 2304 × 1296, 1920 × 1080)
|
|
Sub Stream
|
50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
|
|
Third Stream
|
50Hz: 25 fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30 fps (1280 × 720, 640 × 360, 352 × 240)
|
|
Video Compression
|
Main stream: H.265/H.264,Sub stream: H.265/H.264/MJPEG,Third stream: H.265/H.264
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
H.264 Type
|
Main Profile/High Profile
|
|
H.265 Type
|
Main Profile
|
|
H.264+
|
Main stream supports
|
|
H.265+
|
Main stream supports
|
|
Scalable Video Coding (SVC)
|
Support H.264 and H.265 encoding
|
|
Region of Interest (ROI)
|
|
|
Environment Noise Filtering
|
Yes |
|
Audio Sampling Rate
|
8kHz/16kHz/32kHz/44.1kHZ/48kHz
|
|
Audio Compression
|
G.711/G.722.1/G.726/MP2L2/PCM
|
|
Audio Bit Rate
|
|
|
Simultaneous Live View
|
Up to 6 channels
|
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI
|
|
Protocols
|
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
|
|
User/Host
|
Up to 32 users,3 levels: Administrator, Operator and User,
|
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
|
|
Network Storage
|
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
|
|
Client
|
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
|
|
Web Browser
|
Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11,Plug-in free live view: Chrome 45.0+, Firefox 52.0+
|
|
Alarm Trigger
|
|
|
Day/Night Switch
|
Day/Night/Auto/Schedule/Triggered by Alarm In
|
| DNR |
3D DNR
|
|
Image Enhancement
|
BLC/3D DNR/HLC
|
|
Image Settings
|
|
|
Audio
|
1 input (line in, 3.5 mm), 1 output(3.5 mm), mono sound
|
|
Alarm
|
1 input, 1 output (max. 12 VDC, 30 mA), terminal block
|
|
Video Output
|
1Vp-p composite output (75 Ω) (For adjustment only)
|
|
On-board Storage
|
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
|
|
Hardware Reset
|
Yes |
|
Communication Interface
|
|
|
Basic Event
|
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
|
|
Smart Event
|
Line crossing detection, intrusion detection, unattended baggage, object removal, face detection, scene change detection
|
|
Face Detection
|
Yes
|
|
Exception Detection
|
|
|
Linkage Method
|
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output , Email
|
|
Firmware Version
|
V5.5.80
|
|
General Function
|
One-key reset ，anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening，password protection, watermark, IP address filter
|
|
Startup and Operating Conditions
|
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, terminal block for DC input, PoE(802.3at, class 4)
|
|
Power Consumption and Current
|
12 VDC, 1.2 A, max. 14.4 W, PoE (802.3at, 42.5V to 57V), 0.5 A to 0.3 A, max. 18 W
|
|
Camera Dimension
|
Φ144.1 × 332.7 mm (Φ5. 7"× 13.1")
|
|
Camera Weight
|
|
|
Protection
|
|
