Image Sensor
|
1/2.7" Progressive Scan CMOS
|
|
Max. Resolution
|
1920 × 1080
|
|
Min. Illumination
|
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
|
|
Shutter Time
|
1/3 s to 1/100,000 s
|
|
Day & Night
|
IR Cut Filter
|
|
Angle Adjustment
|
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
|
|
Focal Length & FOV
|
2.8 mm: horizontal FOV 111.6°, vertical FOV 59.1°, diagonal FOV 133.9° 4 mm: horizontal FOV 91.5°, vertical FOV 46.1°, diagonal FOV 109.8° 6 mm: horizontal FOV 56°, vertical FOV 29.8°, diagonal FOV 65.3°
|
|
Lens Mount
|
M12
|
|
Focus
|
Fixed |
|
Aperture
|
F1.6
|
|
Supplement Light Range
|
Up to 30 m
|
|
IR Wavelength
|
850 nm
|
|
Main Stream
|
50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
|
|
Video Compression
|
Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
Baseline Profile/Main Profile/High Profile
|
|
H.265 Type
|
Main Profile
|
|
Region of Interest (ROI)
|
Support 1 fixed region for main stream
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
|
|
Simultaneous Live View
|
Up to 6 channels
|
| API |
Open Network Video Interface, ISAPI
|
|
User/Host
|
Up to 32 users. 3 levels: administrator, operator and user
|
|
Network Storage
|
Support Micro SD/SDHC/SDXC card (256 GB), local storage and NAS (NFS, SMB/CIFS), ANR
|
| Client |
iVMS-4200, Hik-Connect, Hik-Central
|
|
Web Browser
|
Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+
|
|
Image Settings
|
Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
|
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
|
Image Enhancement
|
BLC, 3D DNR
|
|
Wide Dynamic Range (WDR)
|
120 dB
|
|
Ethernet Interface
|
1 RJ45 10 M/100 M self-adaptive Ethernet port
|
|
On-Board Storage
|
Built-in Micro SD slot, up to 256 GB
|
|
Audio
|
-S: 1 input (line in), 1 output (line out)
|
|
Alarm
|
-S: 1 input, 1 output (max. 12 VDC, 30 mA)
|
|
Reset Key
|
Yes |
|
Basic Event
|
Motion detection,video tampering alarm
|
|
Smart Event
|
Line crossing detection, intrusion detection
|
|
Linkage
|
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture
|
|
Power
|
12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug PoE: 802.3af, Class 3, 36 V to 57 V, 0.20 A to 0.15 A, max. 6.5 W
|
|
Dimension
|
Ø110.8 mm × 84.7 mm (Ø 4.4" × 3.3")
|
|
Package Dimension
|
135 mm × 135 mm × 110 mm (5.3" × 5.3" × 4.3")
Approx. 497 g (1.1 lb.)
|
|
With Package Weight
|
Approx. 597 g (1.3 lb.)
|
|
Startup and Operating Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
|
|
Storage Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
|
|
General Function
|
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
|
|
EMC
|
FCC (47 CFR Part 15, Subpart B) CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014) RCM (AS/NZS CISPR 32: 2015) IC (ICES-003: Issue 7) KC (KN32: 2015, KN35: 2015)
|
|
Safety
|
UL (UL 62368-1) CB (IEC 62368-1: 2014+A11) CE-LVD (EN 62368-1: 2014/A11: 2017) LOA (IEC/EN 60950-1) BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005)
|
|
Environment
|
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
|
|
Protection
|
IP67 (IEC 60529-2013) IK10 (IEC 62262: 2002)
|
