Description
xSPECIFICATION:
|
Image Sensor
|
1/2.8" Progressive Scan CMOS
|
|
Min. Illumination
|
Color: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
Slow Shutter
|
Yes |
|
Day &Night
|
IR cut filter
|
|
Wide Dynamic Range
|
|
| Lens |
Fixed lens, 2.8/4 mm
|
|
Auto-Iris
|
No
|
|
Aperture
|
F2.0 |
| FOV |
2.8mm: Horizontal FOV: 114°, vertical FOV: 62°, diagonal FOV: 135° ;4 mm: Horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102°
|
|
Lens Mount
|
|
|
IR Range
|
Up to 30 m
|
|
Wavelength
|
|
|
Max. Resolution
|
1920 × 1080
|
|
Video Compression
|
Main stream: H.265+/H.265/H.264+/H.264;Sub-stream: H.265/H.264/MJPEG
|
|
H.264 Type
|
Baseline Profile/Main Profile/High Profile
|
|
H.265 Type
|
Main Profile
|
|
Video Bit Rate
|
|
|
Region of Interest
|
|
|
Image Enhancement
|
BLC, 3D DNR
|
|
Image Setting
|
Rotate mode, saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser
|
|
Day/Night Switch
|
Day/Night/Auto/Schedule
|
|
Main Stream Max. Frame Rate
|
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720);60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub-stream Max. Frame Rate
|
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
|
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User/Host
|
Up to 32 users,3 levels: Administrator, Operator, and User
|
| Client |
iVMS-4200, Hik-Connect, iVMS-5200
|
|
Web Browser
|
IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
|
|
Alarm Trigger
|
|
|
Communication Interface
|
|
|
Firmware Version
|
5.5.83
|
|
General Function
|
One-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
|
|
Startup and Operating Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, Φ 5.5 mm coaxial power plug; PoE (802.3af, class 0)
|
|
Material
|
Camera body: metal, bottom base : plastic
|
|
Dimensions
|
Camera: 94.4 × Φ110 mm (3.7" × Φ4.3") ;With package: 150 × 150 × 141 mm (5.9" × 5.9" × 5.6")
Camera: Approx. 354 g (0.8 lb.) ;With package: Approx. 681 g (1.5 lb.)
|
|
Power Consumption and Current
|
12 VDC, 0.4 A, max. 5 W; PoE (802.3af, 36 V to 57 V), 0.20 A to 0.10 A, max. 6.5 W
|
|
Interface Protection
|
|
