xSpecifications:
|
Conductor
|
Material: CCA(Copper content 22%–31%) Diameter: 0.57 mm ± 0.01 mm American Wire Gauge: 23AWG |
|
Insulation
|
Material: HDPE Min. Average Thickness: 0.21mm Diameter: 1.02 mm ± 0.06 mm Color (4 Pairs): Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown |
|
Separator
|
Material: PE Specification: Translucent 4.5 × 0.4 mm |
|
Rip Cord
|
Material: Polyester Specification: 500D |
|
Sheath
|
Material: PVC Min. Average Thickness: 0.5 mm Diameter: 6.5 mm ± 0.3 mm Color: Orange |
|
Electrical
|
Max. DC Resistance of a Single Conductor: 11.5Ω/100 m
Min. Insulation Resistance: 5000MΩ·km
Max. DC Resistance Unbalance: 2% (pair intra), 4% (pairs inter)
Dielectric Strength: No breakdown with 1KV DC for 1 min
|
|
Transmission
|
Characteristic Impedance: 100 ± 15Ω Near End Cross Talk: ≥39.30 dB/100 m@250 MHz Max. Attenuation: 34.8 dB/100 m@250 MHz Return Loss: ≥17.3 dB/100 m@250 MHz |
|
Mechanical
|
Tensile Strength: Sheath≥13.5 MPa, insulation≥16 MPa Elongation at Break: Sheath≥150%, insulation≥300% Installation Bending Radius: >8 times of outer cable diameter Conductor Elongation at Break: ≥10% |
|
Environmental
|
Shrinkage of Insulation: ≤5% Color Migration Resistance of Insulation: No migration Sheath Tensile Strength and Elongation at Break after Aging: ≥12.5 MPa, ≥100% Low Temperature Bending Test: No cracking after the test Heat Shock Test: No cracking after the test Operation Temperature: –20°C to +60°C (–4°F to 140°F) Installation Temperature: 0°C to +50°C (32°F to 122°F) Storage Temperature and Humidity: –10°C to +40°C (14°F to 104°F), <60% (RH) |
|
Security
|
Vertical Fire Propagation Test: Comply with IEC 60332-1-2 |
|
Packaging
|
Length: 305.0 m (1000.66 ft) ± 1.5 m (4.92 ft) Packaging Dimensions: 390.0 mm x 390.0 mm x 247.0 mm (15.37"x15.37"x9.73") (L × W × H) Packaging Method: 305.0 m (1000.66 ft) a carton, one protection carton with 2 cartons inside Net Weight: ≥9.2 kg (20.28 lb) Gross Weight: ≥10.2 kg(22.49 lb) |
|
Executive Standard
|
Q/DXJ 067-2019 |
|
Certification
|
CPR Eca |
