Description
xSpecifications:
| Model | MPE-7501-AFAAG-3G |
| ATX Version | ATX 12V Ver. 3.0 |
| PFC | Active PFC |
| Input Voltage | 100-240V |
| Input Current | 10-5A |
| Input Frequency | 50-60Hz |
| Dimensions (L x W x H) | 160 x 150 x 86 mm |
| Fan Size | 120mm |
| Fan Bearing | HDB |
| Efficiency | ≥90% @ Typical Load |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0-50°C |
| Power Good Signal | 100 - 150 ms |
| Hold Up Time | ≥ 16ms |
| MTBF | >100,000 Hours |
| Protections | UVP / OVP / OPP / OTP / SCP / OCP |
| Regulatory | TUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI, BIS, UKCA |
| ATX 24 Pin Connectors | 1 |
| EPS 4+4 Pin Connectors | 1 |
| EPS 8 Pin Connector | 1 |
| SATA Connectors | 12 |
| Peripheral 4 Pin Connectors | 4 |
| PCI-e 6+2 Pin Connectors | 4 |
| 12VHPWR Connector | 1 (1 to 3) |
| 80 PLUS Rating | 80 PLUS Gold |
| Category | Above 750W |
| Series | MWE Gold Series |
| Modular | Fully Modular |
| Form Factor | ATX |
| 80 Plus | Gold |
| Watts | 750W |
Warranty
xWarranty
All products sold by MF Computer Solutions are covered by our 7-Day Direct Replacement Guarantee for factory defects under normal use. Beyond this period, items are protected by their respective manufacturer or supplier warranty, depending on the brand and product category.
Certain products such as monitors and printers may follow specific manufacturer policies (e.g., pixel standards or print count limits).
For complete details, coverage terms, exclusions, and processing guidelines, please refer to our full Warranty Policy page.
